Rigol RSA804 Real-time Spectrum Analyzer, 5 KHz - 4.5 GHz
- Six working modes: GPSA, RTSA, VSA, EMI, ADM and PNOISE
- Frequency range: 5 kHz to 4,5 GHz
- Amplitude Range: DANL to +20 dBm
- 1 GHz Phase Noise: 10 kHz offset, <-110 dBc/Hz, -112 dBc/Hz (typ.)
- RBW, VBW: 1 Hz to 10 MHz
- Max. Analysis Bandwidth: 40 MHz / Max. Real-Time Bandwidth 40 MHz
- Tracking Generator Output Power: - 40dBm to +0dBm
- I/O LAN, USB, HDMI
More detailed specifications and dimensions of available models are specified in data sheet. Detalii
| excl. TVA | € 1 899.00 |
| Preț cu TVA | € 2 259.81 |
| Accesibilitate | On inquiry |
| Cod produs | RIG_RSA804 |
Descriere detaliată Rigol RSA804 Real-time Spectrum Analyzer, 5 KHz - 4.5 GHz descriere producători
The RSA800 Series is designed for electronics R&D, education, and RF enthusiasts. It combines 40 MHz real-time bandwidth, a built-in preamplifier, excellent residual response, a 7-inch multi-touch display, and a full SCPI command set. Covering 5 kHz to 14 GHz, it supports RF measurements for cellular, Wi-Fi, satellite C-/Ku-band, and short-range wireless applications. Optional VSA, ADM, and EMI applications further extend its measurement capabilities.
Compact in Size. Powerful in Performance.
Every model weighs just 1.9 kg. Pack it into the RIGOL Ultra-Portable Instrument Bag and take professional RF testing wherever your work takes you.
Standard USB Type-C PD Power
Supports the mainstream USB Power Delivery (PD) standard via the Type-C interface. Power it with a portable power bank for business travel and field testing, no AC outlet required.
Professional RF Performance for Demanding Applications
Frequency Range: 5 kHz to 4.5 / 8.5 / 14 GHz. Phase Noise: -112 dBc/Hz @ 1 GHz, 10 kHz offset (typ.)
Capture Every Signal in Real Time
40 MHz Real-Time Spectrum Analysis: Reliably captures transient and intermittent signals in complex RF environments. 40 MHz Vector Signal Analysis Bandwidth: Enables in-depth analysis and performance evaluation of a wide range of broadband communication signals.
Premium Features. Standard Included.
No more essential add-ons. The RSA800 comes standard with a built-in preamplifier (PA) and 40 MHz real-time bandwidth. Its integrated tracking generator (TG) can also operate seamlessly as a standalone signal generator (SG).
Comprehensive Measurement Applications
The RSA800 integrates a comprehensive suite of RF measurement applications, with software options available to expand functionality as your testing requirements evolve.
Standard USB, LAN and HDMI Connectivity
USB and LAN interfaces enable remote communication with full SCPI command support. The HDMI output allows connection to an external display for a clearer and more efficient viewing experience.
WebControl
Access and control the instrument directly through a web browser using its IP address, no PC software installation required. Ideal for remote operation and SCPI command debugging.
